Multi-SIM VoIP To GSM/3G Gateway

Multi-SIM VoIP To GSM/3G Gateway

Product Details:

  • Supply Ability : 1000 Piece Per Day
30000 INR/Piece
Get a Price/Quote
Request To Call Back Send Inquiry
X

Price And Quantity

  • 1 Piece
  • 10000.00 - 100000.00 INR/Piece
  • 30000 INR/Piece

Trade Information

  • 1000 Piece Per Day
  • 1 Week
  • Yes
  • All India

Product Description

With ever increasing mobile call traffic and expanding field forces, our organization is engaged in offering a premium array of Multi-SIM VoIP to GSM/3G Gateway. This gateway is manufactured using quality examined components and innovative techniques by dexterous professionals. In order to trunk all GSM, landline and internet connectivity efficiently, this gateway is highly appreciated among customers. Furthermore, we offer this GSM 3G VoIP Gateway to our precious clients at competitive rates.

Key Features

  • Low power consumption
  • Excellent performance
  • Rugged design
  • Maximum throughput
  • 3G Internet Access
  • Penta-band 3G/UMTS
  • TR 069 Auto Configuration
  • SMS Notification
  • TLS/SRTP Security
  • SNMP Monitoring
  • Peer to Peer Calls
  • Hot Swappable SIM Cards
  • Call Details Record

    •  Technical Specifications:



VoIP Parameters:

VoIP ProtocolsSIP v2, SDP, RTP (RFC 2833), SRTP
Network ProtocolsIPv4, TCP, UDP, DHCP, PPPoE, SNTP, NAT, STUN, HTTP, TLS, DynDNS
SIP9 SIP Accounts with Out Bound Proxy Support
NATSTUN and NAT Keep Alive
Voice CodecsG.711 A/µ-Law, G.723, G.729, GSM-FR
Line Echo CancellationG.168 with 128ms Tail Length
Call Progress TonesDial Tone, Ring Back Tone, Busy Tone, Error Tone
VoiceDynamic Jitter Buffer (Adaptive), Comfort Noise Generation and Voice Activity Detection
FaxT.38 (UDTPL), T.38 (RTP) and Pass-Through
Quality of ServiceLayer 3 DiffServ and TOS
Data Network2 Ports Auto MDIX 10/100 BaseT (RJ-45)
SecurityPassword Protected Administration
Physical ConnectorRJ45

GSM Parameters:

GSM Frequency BandGSM: GSM850, EGSM900, DCS1800, PCS 1900
GSM 3G Frequency BandGSM: 850/900/1800/1900
UMTS: 800/850/900/1900/2100
SIM CardOne SIM per GSM Port
SIM Interface1.8V, 3V
Transmission Power2G:
  • Class 4 (2W) at EGSM900 and GSM850 MHz band
  • Class 1 (1W) at DCS1800 and PCS1900 MHz band
3G:
  • Class 4 (33dBm±2dB) for GSM850 and EGSM900
  • Class 1 (30dBm±2dB) for DCS1800 and PCS1900
  • Class E2 (27dBm±3dB) for GSM850 and EGSM900 8-PSK
  • Class E2 (26dBm+3/-4dB) for DCS1800 and PCS1900 8-PSK
  • Class 3 (24dBm+1/-3dB) for UMTS800/850/900/1900/2100
Antenna (Panel Mount)One Antenna per 4 GSM Ports, Fixed Omni Directional Swivel Antenna, 1.8dBi/2.0dBi, 50Ω SMA (Male) Connector

POWER SUPPLY:

Input12VDC, 2A through External Adaptor
Power Consumption15W (Typical)
ConnectorDC Power Jack
LED Indications
  • 1 each for Power and Status
  • 1 each for GSM Port

MECHANICAL:

Dimensions (WxHxD)231 X 162.5 X 55 mm
Unit Weight0.72 Kg (1.58 lbs)
Shipping Weight1.60 Kg (3.52 lbs)
Installation MountingWall Mount and Table-Top
