Specifications:
System Capacity: | |
Expansion Slots | 12 |
Expansion Cards | 4 GSM/3G SIM per Interface Card 16/32 VoIP Channels per Interface Card |
Mobile Port: | |
Frequency Bands | Quad-Band GSM850, EGSM900, DCS1800, PCS1900 Tri-Band WCDMA 850/1900/2100 MHz or Tri-Band WCDMA 900/1900/2100 MHz |
Compliance | ETSI GSM Phase2/2+ |
SIM Interface | 1.8, 3V SIM Interface |
Antenna | Panel Mount or Extended Cable Antenna 1.8/3.0 dBi, 50 Ω SMA (Male) Connector |
VoIP Port: | |
Protocol | SIP v2 |
Physical Connector | Ethernet (RJ45) |
Voice Quality | G.168 Echo Cancellation, Layer3 QoS and DiffServ, CNG |
Voice Codecs | G.711 (A-law, µ-Law), G.723, G.729AB, GSM-FR, GSM-EFR and iLBC Voice Codec |
SIP Trunks | 16 |
Power Supply: | |
Input | Option 1 (Mains): 100-240 VAC, 47-63 Hz Option 2 (DC): 48VDC +/- 20% |
Power Consumption | 50W (Typical) |
Other: | |
Dimensions | 41.2x16.0x25.4cm (16.22"x6.29"x10.0") |
Unit Weight | 6.5kg(14.3lbs) |
Shipping Weight | 9.5kg(20.9lbs) |
Mounting Options | Wall Mount, Table Top and 19" Rack Mount |
Mechanical: | |
Dimensions | 41.2x16.0x25.4cm (16.22"x6.29"x10.0") |
Unit Weight | 6.5kg(14.3lbs) |
Shipping Weight | 9.5kg(20.9lbs) |
Mounting Options | Wall Mount, Table Top and 19" Rack Mount |
Environmental: | |
Operating Temperature | -10° C to +50° C (14° F to +122° F) |
Storage Temperature | -40° C to +85° C (-40° F to +185° F) |
Operating Humidity | 5-95% RH (Non-Condensing) |
Storage Humidity | 0-95% RH (Non-Condensing) at 40° C |
|
|
![]() |
